VC130-12A Polishing Brush Threading Machine
VC130-12A is designed for polishing brushes. Adopting full computer numerical control technology, the whole machine has stable mechanical performance, PLC automatic programming, convenient and quick brush type replacement. There is a hair feeding device, a rubber strip feeding device and a threading device, threading materials such as PP, PE, pig bristle, nylon, Mexican white brown, etc., which can meet the threading production needs of various polishing brushes.
key word:
Vertical machine, horizontal automatic machine, industrial brush machine, auxiliary machine, toothbrush machine
Classification:
E-mail：
Machine features
The VC130-12A is designed for polishing brushes. Using full computer numerical control technology, the mechanical properties of the whole machine are stable, PLC automatic programming, convenient and fast brush type replacement. There is a wool feeding device, a rubber feeding strip device and a threading device, and the threading materials such as PP, PE, bristles, nylon, Mexican white brown, etc., can meet the threading production needs of various polishing brushes.
Technical parameters
| Model | VC130-12A |
| Number of axes | 16 |
| Maximum speed (holes/min) | ≤150 |
| Maximum brush plate diameter (mm | 1300 |
| Filigree/bead length range (mm) | 58-102 |
| Crop pore size range (mm) | 6 |
| Main engine power (KW) | 12 |
| WEIGHT(KGS) | 2700 |
| Overall dimensions (L×W×H)mm | 3760×2310×2110 |
| Servo motor (pcs) | 16 |
| Rated voltage/frequency (V.Hz) | 380V.50Hz |
| Air pressure (MPa) | 0.6-0.8 |
| Number of Seats (pcs) | 1 |
| Air consumption (m³) | 0.5 |
